APLS Thermal Guard Mylar — Enhanced Thermal Protection Improves Patient Care

APLS Thermal Guard Mylar is a portable and disposable absorbent litter that provides maximum thermal protection during emergency transport.

APLS Thermal Guard Mylar provides an integrated system for improved patient care – the highly absorbent cellulose core wicks fluids away from the patient, the Mylar-lined bag and detachable hood retain body heat, and the treated nylon backing protects against wind and moisture.

Eight closable access points enable medical personnel to better treat the patient at point of injury.

APLS Thermal Guard Mylar can retain 1.7 liters of bodily fluid while safely supporting up to 350 pounds.

FEATURES:

• Built-in thermal properties for warmth during transport
• Contains up to 1.7 liters of blood and bodily fluid
• Supports 320 - 350 lbs (145.15 – 158.76 Kg) wet or dry
• 8 (Eight) access points enable treatment at point of injury
• 8 (Eight) reinforced straps allow for easy carrying and transport
• Leak proof nylon backing for additional strength while dragging
• Pockets for medical documents and personal effects
• Detachable, lined hood
• Lightweight, rugged, strong
• Compressed vacuum packed

PART No. and NSN No.:

Part APLSV-2276H/6-2
NSN 6530-01-620-2668

Coast Guard/EMS Orange:

Part APLSV-2276H/6-3
NSN Pending

SPECIFICATIONS:

• Finished Product Size: 22" x 76" (55.88 cm x 193.04 cm)
• Target Absorbency (H₂O): 1,500 – 1,850 grams Target = 1,700 grams, or 1.7 liters
• Pad Thickness: 0.2250" (0.57 cm)
• Pad Weight: 2.9 lbs. Dry Weight (1.32 kg)
• Weight Capacity: 320 - 350 lbs (145.15 – 158.76 Kg)
